Concave Module
The Concave Module for cable ladders provides smooth inward curves, enabling secure and efficient cable routing while maintaining structural stability in tight spaces.
Technical Data
| Code Description | H | W |
| CTCC 050050 | 50 | 050 |
| CTCC 050100 | 50 | 100 |
| CTCC 050150 | 50 | 150 |
| CTCC 050200 | 50 | 200 |
| CTCC 050250 | 50 | 250 |
| CTCC 050300 | 50 | 300 |
| CTCC 050350 | 50 | 350 |
| CTCC 050400 | 50 | 400 |
| CTCC 050450 | 50 | 450 |
| CTCC 050500 | 50 | 500 |
| CTCC 050600 | 50 | 600 |
| CTCC 050700 | 50 | 700 |
| CTCC 050800 | 50 | 800 |
| CTCC 075100 | 75 | 100 |
| CTCC 075150 | 75 | 150 |
| CTCC 075200 | 75 | 200 |
| CTCC 075250 | 75 | 250 |
| CTCC 075300 | 75 | 300 |
| CTCC 075350 | 75 | 350 |
| CTCC 075400 | 75 | 400 |
| CTCC 075450 | 75 | 450 |
| CTCC 075500 | 75 | 500 |
| CTCC 075600 | 75 | 600 |
| CTCC 075700 | 75 | 700 |
| CTCC 075800 | 75 | 800 |
| CTCC 100100 | 100 | 100 |
| CTCC 100150 | 100 | 150 |
| CTCC 100200 | 100 | 200 |
| CTCC 100250 | 100 | 250 |
| CTCC 100300 | 100 | 300 |
| CTCC 100350 | 100 | 350 |
| CTCC 100400 | 100 | 400 |
| CTCC 100450 | 100 | 450 |
| CTCC 100500 | 100 | 500 |
| CTCC 100600 | 100 | 600 |
| CTCC 100700 | 100 | 700 |
| CTCC 100800 | 100 | 800 |
| CTCC 125150 | 125 | 150 |
| CTCC 125200 | 125 | 200 |
| CTCC 125250 | 125 | 250 |
| CTCC 125300 | 125 | 300 |
| CTCC 125350 | 125 | 350 |
| CTCC 125400 | 125 | 400 |
| CTCC 125450 | 125 | 450 |
| CTCC 125500 | 125 | 500 |
| CTCC 125600 | 125 | 600 |
| CTCC 125700 | 125 | 700 |
| CTCC 125800 | 125 | 800 |
| CTCC 150200 | 150 | 200 |
| CTCC 150250 | 150 | 250 |
| CTCC 150300 | 150 | 300 |
| CTCC 150350 | 150 | 350 |
| CTCC 150400 | 150 | 400 |
| CTCC 150450 | 150 | 450 |
| CTCC 150500 | 150 | 500 |
| CTCC 150600 | 150 | 600 |
| CTCC 150700 | 150 | 700 |
| CTCC 150800 | 150 | 800 |
| Ordering code
( Example) |
Code description | CTCC 050050 | C p 1,5 G |
| Type | C. Type Cable Tray | Flanged Type Cable Tray | Normal Type Cable Tray |
| Perforated / Solid | Perforated | solid | |
| Thickness | (1.0 – 1.25 – 1.5 – 2.0 ) |
