FLOOD LIGHT FIXTURE / ASTR 100
Easy mantainance/high durabiilty LED flood light available in different lumen range to meet a variety of appliations.
• Housing made from pure aluminum type 6063 coated with electrostatic grey finish
• Module IP 68 and driver IP 67 protection
• IP 68 cable gland connector to insure no condensation
• Stainless steel screws
Application
Parking lots
Warehouses
Sport fields
Bill boards
Villas
Lighting Specification
| Code | LED Brand | CRI | Efficacy Lm/W | Watt | CCT | Operating Temperature | Dimensions MM (L*W*H) |
| ASTR100-100 | Lumileds | 80 | 12700 | 100 | 3000 K – 4000 K – 6500 K | -40°C~+50°C | H=236, W=324, L=243 |
| ASTR100-150 | Lumileds | 80 | 19050 | 150 | 3000 K – 4000 K – 6500 K | -40°C~+50°C | H= 320, W=324, L=305 |
| ASTR100-200 | Lumileds | 80 | 25400 | 200 | 3000 K – 4000 K – 6500 K | -40°C~+50°C | H= 400 W=324, L=305 |
| ASTR100-250 | Lumileds | 80 | 31750 | 250 | 3000 K – 4000 K – 6500 K | -40°C~+50°C | H=480, W=324, L=385 |
| ASTR100-300 | Lumileds | 80 | 38100 | 300 | 3000 K – 4000 K – 6500 K | -40°C~+50°C | H=560, W=324, L=465 |
